| Precision: | |
|---|---|
| Row of Number: | |
| Type: | |
| Size:: | |
| Brand: | |
| Package: | |
| Quantity: | |
7314 BECBM
HGJX or Customized
7314 BECBM Angular Contact Bearings Single Row Bearings 70x125x24mm factory price
Seals/Shields: No
BE = Single row angular contact bearng
CB = Bearing for universal matching
M = Machined brass cage
Contact angle : 40 Degrees
LImiting Speed (RPM ): 5600
Dimensions: 70x125x24 mm
Single row angular contact ball bearings can accommodate axial loads in one direction only. This type of bearing is typically adjusted against a second bearing. Their bearing rings have an upper and a lower shoulder and are non-separable.
Angular contact ball bearings mainly withstand large one-way axial loads, and the larger the contact angle, the greater the load bearing capacity. Cage materials include steel plate, brass and engineering plastics, and the forming methods include stamping or turning, depending on the bearing form or service conditions. The connection line between the steel ball of the contact ball bearing and the inner and outer full contact points is at the same angle as the radial direction. The contact angle is generally 15°, 30°, 40°.
Packing
1.If no special request, we will use normal packing, bag + box + carton + pallet
2.If need special packing or carding, please list them in your email. We would like to make the customized packing
3.We will use try to protect products in order to avoid any damage in the delivery.
Shipment
1. According to the weight, flange Bearing units can be sent by air or by sea.
2. Customers can also choose their own forwarder.
3. Products will be made after confirming the order, bearings in stock can be delivered within 7 days.
Julie Ma
Mob/WeChat/Skype: 0086 15105314265
7314 BECBM Angular Contact Bearings Single Row Bearings 70x125x24mm factory price
Seals/Shields: No
BE = Single row angular contact bearng
CB = Bearing for universal matching
M = Machined brass cage
Contact angle : 40 Degrees
LImiting Speed (RPM ): 5600
Dimensions: 70x125x24 mm
Single row angular contact ball bearings can accommodate axial loads in one direction only. This type of bearing is typically adjusted against a second bearing. Their bearing rings have an upper and a lower shoulder and are non-separable.
Angular contact ball bearings mainly withstand large one-way axial loads, and the larger the contact angle, the greater the load bearing capacity. Cage materials include steel plate, brass and engineering plastics, and the forming methods include stamping or turning, depending on the bearing form or service conditions. The connection line between the steel ball of the contact ball bearing and the inner and outer full contact points is at the same angle as the radial direction. The contact angle is generally 15°, 30°, 40°.
Packing
1.If no special request, we will use normal packing, bag + box + carton + pallet
2.If need special packing or carding, please list them in your email. We would like to make the customized packing
3.We will use try to protect products in order to avoid any damage in the delivery.
Shipment
1. According to the weight, flange Bearing units can be sent by air or by sea.
2. Customers can also choose their own forwarder.
3. Products will be made after confirming the order, bearings in stock can be delivered within 7 days.
